Productomschrijving
Dit component bord kan worden gebruikt om wetten van Kirchhoff, van Ohm, RC-, Wisselveld- en LRC circuits theorieën met resonantiefrequenties tussen de 55 kHz en 135 kHz te onderzoeken. Het bord bestaat uit: 2 Spoeltjes: 6,8 mH en 2,5 mH 2 condensatoren: 3900 pF, 560 pF 4 weerstanden: 47 kOhm, 3,3 kOhm, en 2 van 1,0 kOhm. Circuit board designed to study and test RC circuits, circuit laws and and theories using PASCO's 580 Universal Interface. Board components can be used to investigate Kirchhoff's Circuit Laws, Ohms's Law, RC Circuits, and A.C. LRC circuit theory with resonant frequencies between 55 kHz and 135 kHz, depending on values used. Includes: -Two inductors: 6.8 mH and 2.5 mH -Two capacitors: 3900 pF and 560 pF -Four resisitors: 47 kO, 3.3 kO, and (2) 1.0 kO
